BAOFENG UV-5RA

Baofeng UV-5RA UHF/VHF Wireless Transceiver 5W with Monochrome Display Black’

Baofeng UV-5RA features include CTCSS and DCS sub-tone encoding and decoding, DTMF tone sending, VOX, multiple tuning pitch options from 2.5 to 25KHz, 128 memories, Narrow and Wide FM modulation selection, low and high power selection, full numeric keypad, adjustable frequency shift for access to repeaters, scan functions, voice guidance and much more.

Category:

Description

Frequency range:

  • [TX] 136 – 174MHz, 400 – 520MHz
  • [RX] 136 – 174MHz, 400 – 520MHz, 68-108MHz (FM Broadcast)

Channel Capacity:

  • 128 Channels
  • Channel Spacing
  • 25KHz (wide band)12.5KHz (narrow band)

Sensitivity: 0.25µV (wide band) =0.35µV (narrow band)

Operation Voltage

  • 7.4V DC ±20%

Battery:

  • 1500mAh

Frequency step:

  • 2.5, 5, 6.25, 10, 12.5, 20, 25, 30 and 50KHz

Antenna:

  • Antenna Connector: SMA-Female / Antenna Impedance: 50O

Accessory Connector:

  • Kenwood 2 Pin Standard

Stability:

  • ±2.5ppm

Output power: 5W / 1W

Audio Power Output: 700mW/10%
